Our Professional Steel Detailing Services for North America
We provide fabrication-ready shop drawings, accurate material take-offs (MTO), and PE-stamped connection designs for commercial, residential, and industrial projects across the USA and Canada — saving time and reducing on-site errors.
Detailed Services
Structural Steel Detailing
- Main steel detailing including beams, columns, and braces.
- Detailed fabrication-ready shop drawings for accurate on-site assembly.
- Compliance with AISC (USA) and CSA (Canada) standards, ensuring your project meets regulations.
- Quality control processes to double-check dimensions, welding, and connection details.
Miscellaneous Steel Detailing
- Stairs, ladders, handrails, platforms, and custom steel components.
- Complete shop drawings for fabrication and installation.
- Detailed annotations to minimize errors during fabrication.
- Optional material take-off and bill of materials for cost estimation.
Material Take-Off (MTO) Preparation
- Accurate estimation of steel quantities to help optimize project costs.
- Reduces wastage and ensures efficient procurement.
- Provides a clear breakdown of materials by type, size, and weight.
- Can integrate directly with fabrication and procurement systems.
Connection Design & PE Stamping
- Design of bolted and welded connections for structural and miscellaneous steel.
- Professional PE stamping for North American approvals.
- Ensures structural integrity, safety, and compliance with AISC and CSA standards.
- Detailed drawings provided for fabrication, installation, and inspection purposes.
Each service we provide is carefully designed to meet the rigorous demands of North American construction projects. From small components to full structural systems, we ensure that every detail is precise, documented, and ready for fabrication.
Why Choose Us?
Precision & Accuracy
Every drawing we produce undergoes rigorous quality checks to ensure the highest level of accuracy and detail precision.
Advanced Technology
We leverage the latest BIM tools and software to deliver cutting-edge solutions that streamline your construction process.
Client-Centric Approach
We don't just deliver drawings — we deliver confidence, clarity, and consistency through long-term collaboration and support.
What We Do
We specialize in complete, detail-driven solutions for the steel construction industry, merging creativity, precision, and advanced BIM tools.
At Xenon Steel Solutions, our focus is on accuracy, efficiency, and client success. Every drawing reflects our commitment to quality, innovation, and long-term collaboration.
We don't just deliver drawings — we deliver confidence, clarity, and consistency.
Steel Detailing & 3D Modeling
Steel Detailing and 3D Modeling by SDS 2 or Tekla with high precision
Connection Design & Engineering
Connection sketches detailed sketches and engineering support for safer, optimized builds
BIM Coordination
Clash detection and multidisciplinary coordination to keep projects on schedule.
Material Takeoff
Accurate estimation and MTO reporting for procurement and cost control.
Shop & Assembly Drawings
Detailed shop, assembly, and erection drawings for fabrication and site teams.
Quality Control
Revision management and QC checks to ensure every drawing is client-ready.
